A4D500AM0905 A4D500-AM09-05 EBM Papst

AC axial fan (compact fan), nominal diameter 500 mm (actual approx. Ø497 mm). Three-phase AC motor, ball-bearing, protection IP54, for cooling heat exchangers, condensers, transformers, drive/control cabinets and general industrial ventilation. Based on the A4D500 family data, the operating range is 400 to 460 V AC three-phase, approx. 1340 to 1510 rpm, with airflow in the order of 5000 to 6400 m3/h-class and power roughly 550 to 720 W depending on variant; the exact airflow, power, speed and voltage for the -AM09-05 build should be confirmed from the ebm-papst datasheet. Aluminium impeller/wall ring typical of the series. Model-code reading: A = axial fan; 4 = AC motor series; D = three-phase; 500 = 500 mm; AM09-05 = motor/voltage/speed/blade variant.
